Nitrogen Cryogenic Cooling Spice Grinder/ Customized cryogenic type Commercial Spice grinder

FOB Reference Price:Get Latest Price
US $15,240-228,600 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
HT
Model Number:
HT-500
Type:
frozen food grinding machine/cryogenic grinder
Product name:
cryogenic type Commercial Spice grinder,industrial spice grinder
After-sales Service Provided:
Engineers available to service machinery overseas
Supply Ability
Supply Ability:
100 Set/Sets per Year
Packaging & Delivery
Packaging Details
standard export case.
Port
Shanghai
Lead Time :
Shipped in 20 days after payment

Cryogenic grinder:

grinding tought,thermoplastic material at cryogenic tempratures means that plastic are brittle enough to be very fine partical size



Composition :

silos, mechanical grinder, fan, cyclone, shaker, liquid nitrogen tank and other components



Application:

The system widely uses for a variety of materials at room temperature can not be crushed



1- thermoplastic material: PP, PE, PS, EVA, PTFE, ABS, MBS, PA, PET.......

2- TPU, Nylon, HDPE, LDPE, LLDPE, rubber, PPT......

3- engineering plastic material: PA, PA6 PA12 PC POM PBT PMMA........

4- special engineering plastic: PEEK, LCP, PTFE, PES, PAI, PAR.......

5- modified plastic: ABS, PP, PVC, PC

6- modified enginerring plastic: PPO, PA, POM, PC, PBT, PET, PSU....

7- plastic rubber materials, kinds of mater batch or pigment: such as white master batch

8- food industry: frozen food pulverizer, chili powder, pepper, white pepper, cinnamon powder ......

9- chemical industry: medicine powders



General food at minus 10-15 degrees can crush crushed to 200 mesh or more. Plastics can be crushed to about minus 30 degrees .



Benefits:

1-smaller particles

2-more uniform particle size distribution

3-efficient process

4-process coolling/temperature control

5-smaller feed ,biger capacity, smaller consumption of nitrogen







Machine configuration:

inverter control:ABB

main pulverizing motor power:Siemens



How does it work?



This deep cold grinder system takes liquid nitrogen as cold source and use the brittleness of

the stuffs under cold temperature.When the cold brittle stuffs enter into the pulverized through the

integrated effect of mutual repeat impact,collision,shearing,rubbing between stuffs and stuffs,stuffs and vane,stuffs and gear plate.



The stuffs after pulverization will be classified and collected.the particles which havent

reached the size requirement will be returned back to the bin and pulverized again.most of the cooling air will be also recycled.
